| Hardware Features |
|
| Model Type |
Desktop / Dual Operation |
| Tape Family |
TZe |
| Tape Sizes |
3.5mm, 6mm, 9mm, 12mm, 18mm, 24mm |
| Tape Length |
26.2′ |
| Tape Technology |
Thermal Transfer |
| Tape Types |
Standard Laminated, Flexible ID, Extra Strength Adhesive , Non-Laminated Iron-on Fabric, Acid Free |
| LCD Display |
20-char. x 3 line Full-color Display with Backlight |
| Backlight |
Yes |
| Maximum Print Resolution |
180 x 360 dpi (when printing from a computer) |
| Maximum Print Speed |
up to 30mm/sec. (using AC adapter); up to 20mm/sec. (using batteries) |
| Keyboard |
QWERTY |
| Cutter |
Auto |
| Batteries |
6 AA Alkaline (optional) |
| ENERGY STAR® Qualified |
Yes |
| AC Adapter |
AD-E001 (included) |
| Interface |
USB (Version 2.0 Full Speed) |
| Software Features |
|
| Number of Fonts |
14 |
| Fonts |
Helsinki, Brussels, US, Florida, Belgium, San Diego, Los Angeles, Calgary, Letter Gothic, Adams, Atlanta, Brunei, Germany, Sofia |
| Font Sizes |
8 (Auto, 6, 9, 12, 18, 24, 36, 42 and 48 pt.) |
| Number of Font Styles |
11 |
| Built-in Symbols |
617 |
| Font Styles |
Normal, Bold, Outline, Shadow, Solid, Italic, Italic Bold, Italic Outline, Italic Shadow, Italic Solid, plus Vertical |
| Max. Print Height |
18.0 mm |
| Maximum Print Lines |
7 |
| Multi-Block |
Yes (Max. 5 blocks) |
| Label Length Setting |
Auto / 30mm – 300mm |
| Auto Incrementation |
Alpha ⁄ numeric |
| Horizontal Alignment |
Left, Center, Right, Justified |
| Vertical Printing |
Yes |
| Mirror Printing |
Yes |
| Text Framing/Fill Pattern |
99 Frames |
| Multi-copy Print |
Up to 99 copies |
| Memory |
Yes (up to 99 labels) |
| Date/Time Stamp |
Yes |
| Built-in Designs/Templates |
25 Label Collection designs |
| Auto Formats |
Asset Management, Files, ID, Media, Signage, Cable Labeling |
| Database Printing |
Yes (using P-touch Editor software) |
| Barcoding |
Yes |
| Barcodes (Stand-alone mode) |
9 kinds (CODE39, ITF 2/5, EAN13, EAN8, UPC-A, UPC-E, CODABAR, GS1-128(UCC/EAN128), CODE128) |
| Barcodes (connected to computer) |
CODE39, UPC-A, UPC-E, ITF (1-2/5), EAN-8, EAN-13, GS1-128 (UCC/EAN-128), CODE128, CODABAR, POSTNET, GS1 DataBar (RSS), QR Code, PDF417, Data Matrix, Laser Bar Code, ISBN-2 (EAN13 AddOn2), ISBN-5 (EAN13 AddOn5), Micro QR Code, MaxiCode, GS-1 Composite, AztecCode |
| Operating System |
Windows® 10, Windows® 8/8.1, Windows® 7, Windows Vista® Mac OS X 10.7.5, 10.8.x, 10.9.x, 10.10.x, 10.11x |
| (PC) Available hard disk space |
70MB |
| (Mac) Available hard disk space |
100MB |
| (PC) Minimum RAM memory |
Windows® XP (128MB or more); Windows Vista® (512MB or more); Windows® 7 (1GB/32-bit) (2GB/64-bit) |
| (Mac) Minimum RAM memory |
Mac OS X 10.4.11 (256MB or more); Mac OS X 10.5.x. (512MB or more); Mac OS X 10.6 (1GB or more) |
| Carton Contents |
|
| Included Items |
0.94″ (24 mm) x 13.1′ (4m) Black on White laminated “TZe” starter tape; AC adapter, USB cable, User’s Manual, P-touch® Editor software/drivers for Windows/Mac (available as a free download) |
| Model Details |
|
| Housing Dimensions |
7.9″ x 7.6″ x 3.4″ |
| Housing Weight |
2.09 lbs. (without batteries) |
| Housing Color |
Black / Dark Gray |
